采用连杆的宽幅型平行开闭气爪

通过以缸体为中心的横向开闭作用进行大范围操作

PH07-06、PH07-10在导杆部位采用交叉滚子轴承，可实现精密开闭

可安装开闭检测磁性开关（PH07-20、PH07-30、PH07-40、PH07-50）

■ Wide type parallel open & close type General Hand
by Link Lever
■ Wide handling with transverse open & close centered
in body
■ Cross Roller Bearing is applied to PH07-06 and
PH07-10.
■ Auto Switch for the detection of position can be
attached
(PH07-20, PH07-30, PH07-40, PH07-50)
